Oil mist lubrication host
Oil mist lubrication host
OMLD-I-10Y
The compact oil mist lubrication main unit adopts simultaneous heating for oil and gas, with automatic heating temperature control and liquid level alarm function. It features simple structure, small footprint, low cost and wide applicability. Easy to install and operate with low power consumption, it is applicable to single-point and multi-point lubrication for short-distance delivery.
Schematic Diagram
Technical Parameter
|
Model |
OMLD-I-10Y |
|
Oil mist flow rate（m3/h） |
1～10 |
|
Oil mist pressure（KPa） |
2～20 |
|
Inlet air pressure（MPa） |
0.2～0.7 |
|
Oil mist concentration（%） |
20～90 |
|
Oil mist particle size（um） |
1～5 |
|
Ambient temperature（℃） |
-40～+50
|
|
Power supply voltage（V） |
220V |
|
Power（KW） |
≤1 |
|
Oil tank capacity（L） |
55 |
|
Weight（kg） |
120
|
|
Transmission distance（m） |
50 |
Optional Configurations
- An auxiliary oil replenishing tank can be installed inside the main unit to realize manual oil refilling.
- Explosion-proof electrical components are optional for use in enterprises with explosion-proof requirements.
