Large oil mist lubrication host
Large oil mist lubrication host
OMLD-I-25YW
The oil mist lubrication main unit is equipped with two independent sets of primary and auxiliary oil mist generating systems. The oil mist generator serves as the core of the oil mist lubrication system.
- Automatic oil replenishment. It monitors the oil tank liquid level in real time and refills oil automatically when the liquid level reaches the lower limit.
- Automatic heating of oil and gas to maintain constant temperature all year round.
- Air pressure safety protection. The system protects the heater from burnout when the inlet air pressure is too low.
- Oil mist concentration detection. The system keeps real-time monitoring on the generated oil mist concentration.
- Man-machine interaction. It supports real-time operation data monitoring, parameter modification and historical operating record inquiry.
- Remote control access.
Technical Parameters
|
Model |
OMLD-I-15YW |
OMLD-I-25YW |
OMLD-I-35YW |
|
Oil mist generation volume（Nm3/h） |
1～15 |
1～25 |
1～35 |
|
Oil mist concentration（g/ m3） |
0～5 |
||
|
Oil mist delivery particle size（µm） |
1～5 |
||
|
Air supply volume（Nm3/h） |
25 |
35 |
45 |
|
Oil mist pressure（KPa） |
2～15 |
||
|
Air supply pressure（MPa） |
0.4～0.7 |
||
|
Maximum oil temperature（℃） |
50 |
||
|
Maximum allowable ambient temperature（℃） |
50 |
||
|
Oil tank capacity（L） |
≥300 |
||
|
Weight（kg） |
552 |
||
|
Explosion-proof grade |
IICT4 Gb |
||
|
Overall protection grade |
IP65 |
||
|
Instrument protection grade |
IP65 |
||
|
Lubricating oil type |
ISO VG46/VG32 |
||
|
Built-in instruments |
Lightning proof |
||
Schematic Diagram
